Beverage Filling SUS304 Stainless Steel 5 Gallon Manual Bottle Washer

Machinery Capacity : 200BPH

Application : Beverage, Manufacturing Plant,Beverage Factory

Packaging Type : Barrel, Bottles, Barrel, Bottles

Packaging Material : Glass, Plastic

Automatic Grade : Semi-automatic, Automatic

Driven Type : Electric

Voltage : 220V/380V/400V

Place of Origin : Shanghai, China

Brand Name : NC, NC

Dimension(L*W*H) : 1250*950*1210

Weight : 195 KG

Warranty : 1 Year

Key Selling Points : Easy to Operate

Filling Material : Water

Filling Accuracy : 100

Machinery Test Report : Provided

Video outgoing-inspection : Provided

Core Components : Motor, Pump, Bearing

Bottle Size : 3/5 Gallon(customized)

Material : SUS304/316

Function : Decapping,bottle inside and outside washing

Capacity : 100-200b/h

Control : PLC Control

Condition : Brand New, New

Type : Filling Machine

Applicable Industries : Manufacturing Plant, Food & Beverage Factory, Farms, Home Use, Food & Beverage Shops

Showroom Location : Philippines, Peru, Mexico, Thailand, UAE, Colombia

Warranty of core components : 1 Year

Price : $650.00/sets 1-1 sets

MOQ : 1 set

Contact Now

Product Overview

SUS304 Stainless Steel 5 Gallon Manual Bottle Washer

This washing machine is mainly use for the 3,5 gallon barrel filling production line, it can wash the barrel mouth and body, so specially use for mineral water etc.
The barrel is first decapped on the right side and then is put into the left part.
The brushes will remove the stain but will not damage the barrel and printed pattern on the barrel, the special brushes on the bottom of the barrel. It can not only wash barrel with flat barrel, but also barrel with sunken bottom.
During the process of cleaning. With the aid of detergent, it can clean the stain completely. On the outlet for barrel, the clean water spraying system will wash away the detergent.
The whole machine has employed an enclosed design, with high reliability and good stability.
This machine is semi-automatic machine which is suitablre for small capacity such like 60barreled/h to 360barreled/h, it is Controlled by manual, there is bottons on the machines.Easy operation and with high efficiency.
Trademark:NC
Beverage Filling SUS304 Stainless Steel 5 Gallon Manual Bottle Washer
PRODUCT SPECIFICATIONS
Power Supply
220V/240V±5% 50HZ
Input Power
1.1KW
Bottle Spec(mm)
Φ270×490×Φ56
Bottle Volume
5 or 3 gallons
Bottle Washing Capacity
120b/h
Out size(mm)
950×950×1210
Packing size(mm):
1150×1050×1350
Weight:
N.W.:195KG G.W.:210KG
PRODUCT CONFIGURATION
Beverage Filling SUS304 Stainless Steel 5 Gallon Manual Bottle Washer
NYLON BRUSHES
Beverage Filling SUS304 Stainless Steel 5 Gallon Manual Bottle Washer
EASY CONTROL CABINET
Beverage Filling SUS304 Stainless Steel 5 Gallon Manual Bottle Washer
WITH PRE RINSING FUNCTION
