2 Liter Semi-Automatic PET Blowing Machine for Small Bottle Production Efficiency

Plastic Processed : PET

Max.Bottle Height(mm) : 380 mm

Neck Diameter(mm) : 30 mm

Max.Bottle Diameter(mm) : 330 mm

Bottle Volume(ml) : 2000 ml

Condition : New

Application : Bottle

Place of Origin : Shanghai, China

Brand Name : NC

Year : 2020

Voltage : 380V/50HZ

Dimension(L*W*H) : 1450*590*1650(mm)

Hollow part volume : 2000ml

High Pressure Valve Brand : AirTac

Clamping Force (kN) : 75

Rotary Cylinder Brand : AirTac

PLC Brand : MITSUBISHI

Power (kW) : 15

Weight (KG) : 1250 KG

Automation : Semi-automatic

Warranty : 1 Year

Key Selling Points : HOT SALE

Showroom Location : Pakistan, Algeria, Chile

Applicable Industries : Manufacturing Plant

Machinery Test Report : Provided

Video outgoing-inspection : Provided

Warranty of core components : 1 Year

Core Components : Bearing, Motor, Gear, PLC, Pressure vessel, Engine

After-sales Service Provided : Engineers available to service machinery overseas

Marketing Type : Factory Direct Sale

Blow Moulding Type : Stretch Blow Moulding

Packaging Details : Standard wooden case

Port : Shanghai

Supply Ability : 50 Set/Sets per Month

Price : $3,400.00/sets 1-1 sets

MOQ : 1 set

Contact Now

2 Liter Semi-Automatic PET Blowing Machine for Small Bottle Production Efficiency

2 Liter Semi-Automatic PET Blowing Machine For Small Bottle

NC series semi automatic bottle blowing machine is the most stable two step blow down equipment of our factory, from one cavity to four cavity, the maximum is 20L,suitable for blowing PET, PP crystal forming kind raw material any shape carbonated beverage bottles, mineral water bottles, cosmetics bottles, wide diameter bottles, high temperature resisting bottles and other plastic container.

2 Liter Semi-Automatic PET Blowing Machine for Small Bottle Production Efficiency

Machine components of

ZG1000A semi-auto blowing machine

Item	Name	Brand
Pneumatic components	Cylinder	TAIWAN Air TAC
Electrical components	Main computer	TAIWAN DELTA
	Human machine interface (HMI)	TAIWAN DELTA
	Relay	KOREA AUTONICS
	Photoelectric switch	TAIWAN Air TAC
Remark	All the components are selected with Internationally applied high-tech products.

1. Technical Parameters of ZG1000A blowing machine

Model	ZG1000A
Output	Based on bottle shape	800-1200PCS/H
Product Specifications	Bottle neck size	10mm-120mm
	Bottle body diameter	15mm-130mm
	Bottle height	50mm-350mm
Mold Specifications	Cavity	2cavities
	Mold thickness	100~250mm
	Max stretching distance	*430380mm**
Machine Power	Power Voltage	380v 3Phase / 220v 3Phase 50/60HZ
Machine Power	Installed power / Actual power	18kw/10kw
Air Source	High pressure air compressor	1.2m3/min 3.0MPa
Air Source	Air dryer	0.6m3/min 1.0MPa
Water chiller	Chilled water yield	15L/min
Blowing machine size	Lengthwidthheight/weight	*17006501700mm/1000kg*
Heater size	Lengthwidthheight/weight	*17006001450mm/300k*

Our company has rich experience to help customers to establish the different production lines for different use, for example. we can arrange technical staff to help customer set up whole production line for mineral water, pure water,cola, milk, juice and vinegar,oil, we are profession for making it. If anyone who is interested in such field wants to buy the whole equipments and machines, pls contact us freely.

We warmly welcome customer to visit our factory at any time,you will see the machine working and running

conditon in our factory!

Responsible Man(General Manager):Jason

Cel.Phone:0086-15221595986

Tel.Phone:0086-21-37575536

2 Liter Semi-Automatic PET Blowing Machine for Small Bottle Production Efficiency Images
